Automatic Hydraulic HOT and COLD Combined Press
(1.5x1.5 Meter)
"At RecoSolution, we invest in creating efficient, Compact & Robust machinery for recycling a sufficient amount of plastic waste."
Providing great services to our customers is our forte and mission. We provide complete technical support, installation, and virtual training for free upon receiving the machine. Along with this, an operating manual and additional 2 years of virtual maintenance are also given.
To see the working video of the machine CLICK HERE
Know More
A 1.5-meter hydraulic sheet press machine with hot press and cold press capabilities and a 10-ton, 8-jack system would typically have specific features to ensure efficient and precise operation. Here are some common features you will find in our machine:
Pressing Mechanism:
Cold Press System: Designed for ambient temperature pressing without the need for additional heating elements.
Hot Press System: Equipped with a heating system, such as electric, to heat the plates during the pressing process.
Hydraulic System:
8-Jack System: Eight hydraulic jacks distribute the pressing force evenly across the sheet material.
10-Ton Capacity: The hydraulic system is capable of exerting a force of 10 tons to press the sheet materials.
Control Panel:
Temperature Control (for hot press): If the machine includes a hot press system, it would have temperature controls for precise heating.
User Interface: A control panel with an intuitive user interface to set parameters such as pressure, temperature (for hot press)
Safety Features:
Safety Guards: Protective guards to prevent operators from coming into contact with moving parts during operation.
Emergency Stop: An emergency stop button for immediate halting of the machine in case of any issues.
Pressing Area:
The machine is designed to handle sheets up to 1.4 meters in length and width.
Platen Surfaces:
Smooth and Flat: The platen surfaces (the pressing plates) are typically smooth and flat to ensure an even distribution of pressure across the sheet.
Materials Compatibility:
Suitable for Various Materials: The machine is designed to work with a variety of plastic waste like HDPE, LDPE, PP, PS, ABS, etc...
Cycle Time:
Adjustable Pressing Time: The machine allows users to set the duration of the pressing cycle, which may vary based on the type and thickness of the material.
Frame Construction:
Sturdy Construction: The frame is constructed from durable materials to provide stability during operation.
Cooling System (for hot press):
If the machine is equipped with a hot press system, it may include a cooling system to quickly reduce the temperature of the platens after pressing.
Maintenance Features:
Accessibility: Easy access to components for maintenance and cleaning purposes.
Footprint:
Compact Design: The machine is designed to occupy a reasonable floor space while still accommodating 1-meter-wide sheets.
Power Supply:
Electrical Requirements: 3 Phase 380V/415V 30KW 50/60HZ
* Customization is available as per your need.
AUTOMATIC HYDRAULIC SYSTEM:
1) 10 Ton double-stroke jack
2) Pressure Gauge monitoring system
3) Hand lever-operated mechanism
4) Directional control valve
5) 2 HP Motor
6) Overload switch protection for motor
7) Pressure Pump
8) Oil tank – 36 Liter
Our Sheetpress systems are CE CERTIFIED Under the below directives and Standards
1. 2006/42/EC
2. 2014/35/EU
3. EN ISO 12100: 2010
4. EN 60204-1: 2018
We Ship all Over the World
Machine specifications
- Other
- Provided by seller
Select the plastic types this item can process.
Not sure about plastic types? Learn more on the Precious Plastic Academy.
- HDPE (2)
- LDPE (4)
- PP (5)
- PS (6)
- Other (7)
- 220V - 240V
- 380V - 400V
Safety & compliance
- CE (European Union)
- ISO 9001
Sheetpress details
Indicates whether a cold press is available or included with this machine.
Cold pressing is an essential step in the sheet pressing process: after heating, the sheet needs to be pressed under pressure while cooling to ensure a flat, even result.
Having a cold press integrated or available with your machine simplifies the workflow significantly. Learn more about the sheet pressing workflow in this Academy article.
