| Turn recycled PP and HDPE into branded buttons at desktop scale, three sizes available |
Button Mould (3 Sizes)
The Premium Button Mould from Sustainable Design Studio is a CNC-machined aluminium injection mould that produces a full batch of uniform buttons in a single shot. Available in three sizes (Ligne 32 Large 20mm, Ligne 24 Medium 15.3mm, Ligne 16 Small 10.7mm), each mould runs a complete cycle in under 2 minutes on the Injection Mini V2 or Arbour Injection Machine V2.
Each size is sold as a separate mould, machined from solid 7075 aerospace-grade aluminium for surface finish, heat dissipation, and consistent part quality. All three variants include dedicated logo space on the button face, ideal for branded fashion runs, uniform buttons, and small-batch production.
Perfect for
|
Key features
|
CNC-machined from 7075 aerospace-grade aluminium For surface finish, heat dissipation, and part consistency. |
Three size options Ligne 32 (20mm), Ligne 24 (15.3mm), Ligne 16 (10.7mm) button diameters. |
|
15 to 27 cavities per shot A full batch of buttons in a single cycle. |
Mould cycle time under 2 minutes per shot Real throughput depends on your machine's plasticising rate. |
|
Custom logo space on every variant Sized to suit each button diameter. |
Compatible with Injection Mini V2 and Arbour Injection Machine V2 Using the SDS tapered hybrid nozzle. |
Configuration options
|
Ligne 32 Large: 20mm button, 15 cavities per shot. |
|
Ligne 24 Medium: 15.3mm button, 18 cavities per shot. |
|
Ligne 16 Small: 10.7mm button, 27 cavities per shot. |
Each size is sold as a separate mould. All three variants include mounting bolts and a digital user guide.
What's in the box
- 1x Premium Button Mould, 7075 aluminium (one size per order)
- 1x Set of mounting bolts
- 1x Digital user guide (QR code)
Technical specifications
| Specification | Detail |
| Mould material | 7075 aerospace aluminium alloy |
| Plastic compatibility | PP, HDPE |
| Recommended temperature | 220°C (PP) |
| Button size | Large 20 mm, Medium 15.3 mm, Small 10.7 mm |
| Cavities per shot | Large 15, Medium 18, Small 27 |
| Part volume | Large 0.65 cm³, Medium 0.35 cm³, Small 0.2 cm³ |
| Shot volume | Large 17.7 cm³, Medium 13.3 cm³, Small 12.8 cm³ |
| Cycle time | Less than 2 minutes per shot, mould-side |
| Mould size | Large 130 x 175 x 50 mm, Medium 120 x 150 x 50 mm, Small 120 x 150 x 50 mm |
| Estimated life | 10,000+ cycles |
| Custom logo space | Large 2.2 x 53 mm, Medium 1.8 x 40 mm, Small 1.3 x 28 mm |
| Nozzle type | SDS tapered hybrid (alternatives available on request) |
| Machine compatibility | Injection Mini V2, Arbour Injection Machine V2 |
About Sustainable Design Studio
Sustainable Design Studio is a UK based manufacturer of desktop plastic recycling machines and premium injection moulds. Founded by one of the original designers behind the Precious Plastic V4 Brick, we have a full time team dedicated to helping you get started with plastic recycling. Our equipment is in use in 93+ countries across 6 continents.
We offer tracked international shipping, accept purchase orders, and provide invoices for universities and government bodies. Every order comes with customer support from people who designed and built the machines.
Questions before you buy? Send us a message and we will get back to you promptly.
| Contact us before you buy |
Looking for more?
We also make the Injection Mini V2, Desktop Shredder V2, Arbour Injection Machine V2, Filament Maker, and a full range of Premium Moulds.
| Browse all our products |
