Fully Automatic Vertical Injection Machine:

DESIGN PARAMETERS WITH STANDARD SUPPLY:

1) 450 mm / 30 ID /40 OD / Barrel Hydraulic system of 2 HP Injection Molding Machine – HDPE/PP/LDPE/PS: 1 nos.

2) Process Control Panel synchronized by one master control: 1 nos.

3) Auto Mould filling station: 1 nos.



SPECIFIC DATA

  • Material to be processed: Recycled HDPE/PP/LDPE/PS
  • Hydraulic Strock 450 mm.
  • Main Jack Capacity 5 Ton
  • Barrel Size: L- 450 mm, OD-40mm, ID- 30mm
  • Advanced extrusion control with optimized workflow to fill molds
  • Total Connected Load: 4-5* kW (Approx.)



MAIN INJECTION

  • Barrel Type: Smooth Feed Barrier type high speed design
  • Barrel Material: EN 41B Nitro alloy steel duly gas nitride
  • Smooth Injection rod tip to push the material into barrel nozzle.
  • Main Motor: AC Motor 2HP
  • Barrel Heating Zones: 3 Heating Zones (Ceramic Band Heater with Energy Saving)
  • Barrel Heating Loads: 3 kW.
  • Hopper Loader: M.S. Fabricated Hopper
  • Structure: MS fabricated heavy‐duty structure made from Channels and Covered with sheet
  • Enclosed Hydraulic system and mold filling station.
Customization is available as per your need.
Carbon Fusion is an Indian company that is registered with a VAT (GST) number of 09CAUPS1198H1ZU and provides worldwide shipping services


clint%20logo%20with%20QR_page-0001.jpg?1675064896426

CE Certified:
Yes
Condition:
New
Country of Origin:
INDIA
Dimensions of the listing:
180 x 120 x 180CM
Frequency (Hz):
60 Hz
Made according to the Precious Plastic drawings? :
No
Motor Power (kW):
4kW
Plug type:
  • Type D: India
Voltage:
220V - 240V
Voltage:
220V - 240V
Weight (KG):
60KG
