Extruder V3 Parameters

General Specifications:

• Screw Extruder: Smooth Screw, L 599mm / D 26mm, 1.5HP – Suitable for HDPE, PP, LDPE, PS, PET (1 unit).
• Control Panel: Synchronized by a master control.
• Material Compatibility: Recycled HDPE, PP, LDPE, PS, PET (grinded scrap).
• Max Job Size: Up to 5ft length.
• Screw Specifications: RPM 70, Size L 599mm, OD 26mm.
• Barrel Specifications: L 620mm, OD 34mm, ID 26mm.
• Output: Varies based on material.
• Safety Features: Advanced extrusion control for optimized mold filling.
• Total Load: ~5 kW.

Main Extruder:

• Barrel Type: Smooth Feed Barrier, high-speed design.
• Material: EN 41B Nitro-alloy steel.
• Gear Reducer: Helical Gearbox with heavy-duty thrust bearing.
• Main Motor: 1.5HP AC Motor.
• Heating Zones: 2 (Ceramic Band Heater, 3 kW total).
• Hopper: MS Fabricated.
• Structure: MS.

Process Control Panel:

• Temperature Control: PID Controller (autotuning, dual display).
• Electrical Components: Reputed MCBs, Amp Meter, Contactors, Synchronization card, inline choke, and standard PVC wiring.

Additional Features:

• Customization: Available.
• International Shipping: Yes.
• Technical Support: 24/7 customer support available.
• Certifications: CE certified.

Company Information:

We are registered company in India under VAT(GST) number 24DIFPR6832B2ZC.
With this number, we can do business with you and provide an invoice.

Shipping Information:

• For orders outside of India, shipping will be made through CFR (delivery to the main port).
• The client is then responsible for the import and local transport from the main port.
• For a more precise quote to the nearest port, please contact us.

Contact Information:

If you have any questions, feel free to contact us via the Bazar messenger.
